Key Features
1. Power end
- Eccentric type balanced crankshaft forged alloy steel for less vibration, noise and longer bearing life.
- All High Strength Steel Fabricated and Stress Relieved Power End.
- Continuous herringbone gear
- Replaceable crosshead guide
2. Fluid end
- API Standard 7# Valves, Seats, Liners, Piston Rods, and Pistons.
- Quick Change Buttress Threaded Valve and Fluid End Covers.
3. Lubrication and other system
- Triple Redundant (Failure Proof) Power End Lube System: Internal Splash / Gravity Feed, Internal Gear Driven Pump, and External Gear Pump, Electric Motor Driven.
- Required central lubrication manifold system with copper tubing for feeding main, eccentric, and pinion bearings. Pressurized lubrication is also required to the lower crosshead slide for longer crosshead life.
- Required High Capacity Recirculating Liner Wash System, consisting of: Electric Motor Driven Liner Wash Pump, and Baffled Recirculation Collection Tank System.
4. Spraying system
- Consist of centrifugal spray pump, cooling water tank and spray pipe.
- Cool and wash the piston and liner so as to extend the service life.
- Cooling medium is water or water based lubricant.
5. Super charging system
- To avoid air lock at suction inlet of the pump set.
- Consist of super charging pump, butterfly valve, pipeline etc.
- Super charging pump is driven by ex-proof motor.
Specifications
|
Model
|
RGF-1600
|
|
Rated power, kW(hp)
|
1193(1600)
|
|
Max. liner bore, mm (in)
|
180 (7-1/2)
|
|
Stroke, mm(in)
|
305 (12)
|
|
Rated speed, spm
|
120
|
|
Gear ratio
|
4.206
|
|
Suction flange size, in
|
12
|
|
Discharge flange size, in
|
5
|
|
Valve pot
|
API 7#
|
|
Weight, kg
|
25,417
|
Performance chart for RGF1600 mud pump
|
RGF-1600 Mud Pump Displacement and Pressure Relation Chart
|
|
Liner Diameter
|
Size Inch
|
7
|
6-3/4”
|
6-1/2”
|
6-1/4”
|
6”
|
5-1/2”
|
5
|
|
Discharge Pressure
|
MPa
|
23.6
|
25.4
|
27.4
|
29.6
|
32.1
|
34.5 |
34.5
|
|
Psi
|
3420
|
3684
|
3974
|
4293
|
4655
|
5000
|
5000
|
|
Stroke
|
Input Power
|
Displacement (L/s)
|
|
SPM
|
KW
|
HP
|
|
120
|
1193
|
1600
|
45.41
|
42.22
|
39.15
|
36.20
|
33.36
|
28.03
|
23.17
|
|
110
|
1093
|
1466
|
41.63
|
38.7
|
35.89
|
33.18
|
30.58
|
25.69
|
21.24
|
|
100
|
994 |
1333
|
37.84
|
35.18
|
32.63
|
30.17
|
27.8
|
23.36
|
19.31
|
|
90
|
895
|
1200
|
34.06
|
31.67
|
29.36
|
27.15
|
25.02
|
21.02
|
13.38
|
|
50
|
497
|
666
|
18.92
|
17.59
|
16.31
|
15.08
|
13.9
|
11.68
|
9.65
|
|
1
|
9.93
|
13.3
|
0.3784
|
0.3518
|
0.3263
|
0.3017
|
0.278
|
0.2336
|
0.1931
|
Packaging & Shipment
Packaging type: Seaworthy packing
Exporting port: Tianjin, Shanghai
FAQ
1. Who are you?
Tianjin Geostar Petroleum Equipment Co., Ltd. are integrated oilfield pump solution provider. We produce GST brand centrifugal pump and supply RG brand F series drilling mud pump, parts, plunger pump etc.
2. Why should we buy from you?
a. Competitive price
b. Quick delivery
c. Worry free after-sales service. Refund or sending new goods if quality issues can't be resolved by after-sales service.
3. Is after-sale service available to your products?
Yes, we have professional after-sale service team which will offer you the site commissioning service. Engineers are available to be abroad for service.
4. What is your warranty policy?
We offer 12 months limited warranty for complete set of equipment or machinery.
5. What is the delivery time for your product?
Generally, ready stock for commonly used parts, mud pump unit and complete equipment depends upon technical configuration.
